LAUNCHXL-F28377S overview
Table 5. LAUNCHXL-F28377S Bill of Materials (continued)
Item Ref Varient Qty Description Mfg Part Number Vendor Stk Number
C8, C10, C11 All 3 CAP CER 4.7 µF 6.3 V 20% X5R
0402
Murata Electronics
North America
GRM155R60J475ME4
7D
Digikey 490-5915-1-ND
C6, C7, C19 All 3 CAP CER 1 µF 6.3 V 10% X5R
0402
Murata Electronics
North America
GRM155R60J105KE1
9D
Digikey 490-1320-1-ND
C80 All 1 CAP CER 22 µF 4 V 20% X6S
0603
Murata Electronics
North America
GRM188C80G226ME
A0D
Digikey 490-7196-1-ND
C45 All 1 CAP CER 22 µF 10 V 10% X7R
1210
Murata Electronics
North America
GRM32ER71A226KE2
0L
Digikey 490-1876-1-ND
C15 All 1 CAP CER 3.3 µF 4 V 20% X5R
0402
TDK Corporation C1005X5R0G335M05
0BB
Digikey 445-7397-1-ND
C25 All 1 CAP CER 820 pF 50 V 10% X7R
0402
Murata Electronics
North America
GRM155R71H821KA0
1D
Digikey 490-3250-1-ND
C3, C4, C17, C18 All 4 CAP CER 36 pF 50 V C0G 0402 TDK Corporation C1005C0G1H360J Digikey 445-4903-2-ND
R15, R33, R43, R44 All 4 RES SMD 0.0 Ω JUMPER 1/10W Panasonic Electronic
Components
ERJ-2GE0R00X Digikey P0.0JCT-ND
R11, R52 All 2 RES SMD 0.56 Ω 1% 1/6W 0402 Panasonic Electronic
Components
ERJ-2BQFR56X Digikey P.56AKCT-ND
R47 All 1 RES SMD 100K Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF1003X Digikey P100KLCT-ND
R12, R14, R35, R42, R45 All 5 RES SMD 10K Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF1002X Digikey P10.0KLCT-ND
R34 All 1 RES SMD 120 Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF1200X Digikey P120LCT-ND
R24 All 1 RES SMD 12K Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF1202X Digikey P12.0KLCT-ND
R53 All 1 RES SMD 178K Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF1783X Digikey P178KLCT-ND
R3, R13, R22, R23, R29,
R36, R37, R40, R41, R48,
R49, R50, R51
All 13 RES SMD 1K Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF1001X Digikey P1.00KLCT-ND
R7 All 1 RES SMD 1M Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF1004X Digikey P1.00MLCT-ND
R2, R6, R8, R9, R10, R31 All 6 RES SMD 2.2K Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF2201X Digikey P2.20KLCT-ND
R17 All 1 RES SMD 30.1K Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF3012X Digikey P30.1KLCT-ND
R26, R27, R38, R39 All 4 RES SMD 330 Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF3300X Digikey P330LCT-ND
R55 All 1 RES SMD 39.2K Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF3922X Digikey P39.2KLCT-ND
