Texas Instruments LAUNCHXL-F28377S User Manual

www.ti.com LAUNCHXL-F28377S Hardware
17
SPRUI25D–June 2015–Revised March 2019
Submit Documentation Feedback
Copyright © 2015–2019, Texas Instruments Incorporated
LAUNCHXL-F28377S overview
Table 5. LAUNCHXL-F28377S Bill of Materials (continued)
Item Ref Varient Qty Description Mfg Part Number Vendor Stk Number
R54 All 1 RES SMD 64.9K Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF6492X Digikey P64.9KLCT-ND
R1, R4, R5, R46 All 4 RES SMD 820 Ω 1% 1/10W 0402 Panasonic Electronic
Components
ERJ-2RKF8200X Digikey P820LCT-ND
D3 All 1 DIODE SCHOTTKY 40 V 1A
SOD123
Diodes Incorporated 1N5819HW-7-F Digikey 1N5819HW-FDICT-ND
D1, D4 All 2 LED 1X0.5 MM 570NM GN WTR
CLR SMD
Kingbright APHHS1005CGCK Digikey 754-1101-1-ND
D8, D9 All 2 LED 1X0.5 MM 630NM RD WTR
CLR SMD
Kingbright APHHS1005SURCK Digikey 754-1104-1-ND
D7, D10 All 2 LED BLUE 470NM WTR CLEAR
SMD
Kingbright APHHS1005QBC/D Digikey 754-1504-1-ND
L8 All 1 FIXED IND 1 UH 1.62A 40 MOHM
SMD
Murata Electronics
North America
LQH3NPN1R0NJ0L Digikey 490-5342-1-ND
L7 All 1 FIXED IND 2.2 UH 1.9A 60 MOHM
SMD
Sumida America
Components Inc
CDRH2D18/
HPNP-2R2NC
Digikey 308-2295-1-ND
L6 All 1 FIXED IND 3.3 UH 1.8A 85 MOHM
SMD
Sumida America
Components Inc
CDRH3D16/
HPNP-3R3NC
Digikey 308-1981-1-ND
L5, L11 All 2 FERRITE BEAD 220 Ω 0402 Taiyo Yuden BKP1005EM221-T Digikey 587-3290-1-ND
L3, L4 All 2 FERRITE CHIP 60 Ω 1700MA 0402 Murata Electronics
North America
BLM15PD600SN1D Digikey 490-5201-1-ND
L1, L2 All 2 FERRITE CHIP 600 Ω 300MA 0402 Murata Electronics
North America
BLM15AG601SN1D Digikey 490-1006-1-ND
U8 All 1 IC EEPROM 2K-BIT 3 MHZ SOT23-
6
Microchip Technology 93LC56BT-I/OT Digikey 93LC56BT-I/OTTR-ND
U6 All 1 IC USB HS DUAL UART/FIFO 64-
QFN
FTDI, Future
Technology Devices
International Ltd
FT2232HQ-REEL Digikey 768-1025-2-ND
U5 All 1 ISOLAT DGTL 2.5KVRMS 4CH 16-
SOIC
Texas Instruments ISO7240CDWR Digikey ISO7240CDWR-ND
U7 All 1 ISOLAT DGTL 3KVRMS 3CH 16-
SOIC
Texas Instruments ISO7231CDWR Digikey ISO7231CDWR-ND
U12 All 1 IC REG BOOST ADJ 2.1A SOT23-5 Texas Instruments LMR62421XMFE/
NOPB
LMR62421XMFE/NOPB
CT-ND
U3 All 1 IC CAN TRANSCEIVER 3.3 V 8-
SOIC
Texas Instruments SN65HVD234DR Digikey 296-27991-1-ND
U9 All 1 IC BUFF/DVR DL NON-INV
SOT236
Texas Instruments SN74LVC2G07DBVR Digikey 296-13494-2-ND
U1 All 1 IC MCU 32-BIT 1024KB 100LQFP Texas Instruments TMX320F28377SPZP
T
Digikey 296-39644-ND
