OMAP-L138/C6748 Low-Cost Development Kit (LCDK)
4. SD/MMC Flashing
a. Connect to the Arm or DSP with the GEL file loaded, which auto-initializes the DDR.
b. Open (CCS3) or import (CCS4, CCS5) the NANDWriter_ARM or the NANDWriter_DSP project.
c. Modify the #define "NANDWIDTH_8" to "#define NANDWIDTH_16" in nandwriter.c.
d. Rebuild and run the code.
For more information, see the OMAPL138/C6748 ROM Bootloader Resources and FAQ
4 LCDK Features
4.1 Video
Table 9. Video DAC
Component U13
Part Number THS8135PFP
Data Sheet SLAS343
Description Texas Instruments 10-bit Video DAC
Table 10. Video Decoder
Component U21
Part Number TVP5147M1PFP
Data Sheet SLES099
Description Texas Instruments 10-bit Digital Video Decoder
4.2 Memory
Table 11. NAND Flash
Component U18
Part Number MT29F4G16ABADAH4-IT:D
Data Sheet 4Gb, 8Gb, 16Gb: x8, x16 ECC NAND M60A Data Sheet
Description Micron 4Gbit NAND Flash (x16 data width)
Table 12. DDR2 SDRAM
Component U17
Part Number W971GG6KB-25
Data Sheet WBNDS03072-1
Description Micron 4Gbit NAND Flash (x16 data width)
4.3 Connectivity
Table 13. Ethernet PHY
Component U23
Part Number LAN8710A-EZK
Data Sheet Microchip
Description Micron 4Gbit NAND Flash (x16 data width)
