7.6 Power Supervisor Characteristics
Recommended operating conditions; T
A
= –10 to 85°C unless otherwise noted
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
UV_LDO3V3
Undervoltage threshold for LDO_3V3. Locks out 1.8-V
LDOs
LDO_3V3 rising 2.2 2.325 2.45 V
UVH_LDO3V3 Undervoltage hysteresis for LDO_3V3 LDO_3V3 falling 20 80 150 mV
UV_VBUS_LDO Undervoltage threshold for VBUS to enable LDO VBUS rising 3.35 3.75 3.95 V
UVH_VBUS_LDO Undervoltage hysteresis for VBUS to enable LDO VBUS falling 20 80 150 mV
UV_PCBL Undervoltage threshold for PP_CABLE PP_CABLE rising 2.5 2.625 2.75 V
UVH_PCBL Undervoltage hysteresis for PP_PCABLE PP_CABLE falling 20 50 80 mV
UV_5V0 Undervoltage threshold for PP_5V0 PP_5V0 rising 3.5 3.725 3.95 V
UVH_5V0 Undervoltage hysteresis for PP_P5V0 PP_5V0 falling 20 80 150 mV
OV_VBUS
Overvoltage threshold for VBUS. This value is a 6-bit
programmable threshold
VBUS rising 5 24 V
OVLSB_VBUS
Overvoltage threshold step for VBUS. This value is the LSB
of the programmable threshold
VBUS rising 328 mV
OVH_VBUS Overvoltage hysteresis for VBUS VBUS falling, % of OV_VBUS 0.9% 1.3% 1.7%
UV_VBUS
Undervoltage threshold for VBUS. This value is a 6-bit
programmable threshold
VBUS falling 2.5 18.21 V
UVLSB_VBUS
Undervoltage threshold step for VBUS. This value is the
LSB of the programmable threshold
VBUS falling 249 mV
UVH_VBUS Undervoltage hysteresis for VBUS VBUS rising, % of UV_VBUS 0.9% 1.3% 1.7%
UVR_OUT3V3
Configurable undervoltage threshold for VOUT_3V3 rising.
Deasserts RESETZ
Setting 0 2.019 2.125 2.231
V
Setting 1 2.138 2.25 2.363
Setting 2 2.256 2.375 2.494
Setting 3 2.375 2.5 2.625
Setting 4 2.494 2.625 2.756
Setting 5 2.613 2.75 2.888
Setting 6 2.731 2.875 3.019
Setting 7 2.85 3 3.15
UVRH_OUT3V3 Undervoltage hysteresis for VOUT_3V3 falling OUT_3V3 falling 30 50 mV
TUVRASSERT
Delay from falling VOUT_3V3 or MRESET assertion to
RESETZ asserting low
75 μs
TUVRDELAY
Configurable delay from VOUT_3V3 to RESETZ
deassertion
0 161.3 ms
7.7 Power Consumption Characteristics
(4)
Recommended operating conditions; T
A
= 25°C (Room temperature) unless otherwise noted
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
IVIN_3V3
Sleep
(1)
VIN_3V3 = VDDIO = 3.45 V, VBUS = 0,
PPCABLE = 0; 100-kHz oscillator running
58 µA
Idle
(2)
VIN_3V3 = VDDIO = 3.45 V, VBUS=0, PPCABLE
= 0; 100-kHz oscillator running,
48-MHz oscillator running
1.66 mA
Active
(3)
VIN_3V3 = VDDIO = 3.45 V, VBUS = 0,
PPCABLE = 0; 100-kHz Oscillator running,
48-MHz oscillator running
5.64 mA
(1) Sleep is defined as Type-C cable detect activated as DFP or UFP, internal power management and supervisory functions active.
(2) Idle is defined as Type-C cable detect activated as DFP or UFP, internal power management and supervisory functions active, and a
selectable clock to the digital core of 3 MHz or 4 MHz.
(3) Active is defined as Type-C cable detect activated as DFP or UFP, internal power management and supervisory functions active, all
core functionality active, and the digital core is clocked at 12 MHz.
(4) Application code can result in other power consumption measurements by adjusting enabled circuitry and clock rates. Application code
also provisions the wake=up mechanisms (for example, I
2
C activity and GPIO activity).
