11 TPS65994EVM Bill of Materials
Table 11-1 lists the TPS65994EVM bill of materials.
Table 11-1. TPS65994EVM BOM
Designator QTY Value Description Package Reference Part Number Manufacturer
!PCB1 1 Printed Circuit Board PSIL053 Any
C1, C2, C6, C7 4 220pF CAP, CERM, 220 pF, 50 V, +/- 10%, X7R, AEC-Q200
Grade 1, 0201
0201 CGA1A2X7R1H221K030BA TDK
C3, C8 2 10uF CAP, CERM, 10 uF, 25 V, +/- 20%, X5R, 0603 0603 GRM188R61E106MA73D MuRata
C4, C5, C50 3 10uF CAP, CERM, 10 uF, 10 V, +/- 20%, X5R, 0402 0402 CL05A106MP5NUNC Samsung Electro-Mechanics
C9, C29, C31, C37, C38,
C39, C40
7 0.1uF CAP, CERM, 0.1 uF, 50 V, +/- 10%, X7R, 0402 0402 C1005X7R1H104K050BB TDK
C10, C11, C12, C13 4 22uF CAP, CERM, 22 uF, 35 V, +/- 20%, X5R, 0805 0805 C2012X5R1V226M125AC TDK
C14, C15 2 0.1uF CAP, CERM, 0.1 uF, 35 V, +/- 10%, X5R, 0402 0402 GMK105BJ104KV-F Taiyo Yuden
C16, C17, C19, C20 4 100uF CAP, TA, 100 uF, 6.3 V, +/- 20%, 0.015 ohm, SMD 3528-21 T520B107M006ATE015 Kemet
C18, C45, C46, C47 4 47uF CAP, CERM, 47 uF, 10 V, +/- 20%, X5R, 1206 1206 C3216X5R1A476M160AB TDK
C21, C22 2 4.7uF CAP, CERM, 4.7 uF, 6.3 V, +/- 20%, X5R, 0402 0402 GRM155R60J475ME87D MuRata
C23_PA, C23_PB,
C24_PA, C24_PB,
C25_PA, C25_PB,
C26_PA, C26_PB, C44
9 0.01uF CAP, CERM, 0.01 uF, 50 V, +/- 5%, X7R, 0402 0402 C0402C103J5RACTU Kemet
C27_PA, C27_PB 2 1uF CAP, CERM, 1 uF, 6.3 V, +/- 20%, X5R, 0201 0201 GRM033R60J105MEA2D MuRata
C28_PA, C28_PB 2 0.1uF CAP, CERM, 0.1 uF, 100 V,+/- 10%, X7R, AEC-Q200
Grade 1, 0603
0603 GCJ188R72A104KA01D MuRata
C30, C32 2 4.7uF CAP, CERM, 4.7 uF, 10 V, +/- 20%, X5R, 0402 0402 C1005X5R1A475M050BC TDK
C33 1 180pF CAP, CERM, 180 pF, 50 V, +/- 5%, C0G/NP0, 0603 0603 06035A181JAT2A AVX
C34_PA, C34_PB 2 4.7uF CAP, CERM, 4.7 uF, 35 V, +/- 10%, X5R, 0603 0603 GRM188R6YA475KE15D MuRata
C42, C43 2 10pF CAP, CERM, 10 pF, 50 V, +/- 5%, C0G/NP0, 0603 0603 06035A100JAT2A AVX
C48, C52 2 1uF CAP, CERM, 1 uF, 35 V, +/- 10%, X5R, 0402 0402 GRM155R6YA105KE11D MuRata
D1, D2, D14, D15, D16,
D17, D18, D19, D20,
D21, D22, D23, D24
13 White LED, White, SMD 0402, White LW QH8G-Q2S2-3K5L-1 OSRAM
D3 1 24V Diode, TVS, Bi, 24 V, 70 Vc, SOD323, 2-Leads, Body
1.9x1.45mm, No Polarity Mark
SOD323, 2-Leads, Body
1.9x1.45mm, No Polarity Mark
PESD24VL1BA,115 NXP Semiconductor
D4 1 Blue LED, Blue, SMD LED_0603 150060BS75000 Wurth Elektronik
D5_PA, D5_PB 2 30V Diode, Schottky, 30 V, 2 A, 2-XFDFN 2-XFDFN NSR20F30NXT5G ON Semiconductor
D6_PA, D6_PB, D7_PA,
D7_PB, D8_PA, D8_PB,
D9_PA, D9_PB, D10_PA,
D10_PB, D11_PA,
D11_PB, D12_PA,
D12_PB, D13_PA,
D13_PB
16 1-Channel ESD Protection Diode for USB Type-C and
Thunderbolt 3, DPL0002A (X2SON-2)
DPL0002A TPD1E01B04DPLR Texas Instruments
TPS65994EVM Bill of Materials www.ti.com
32 TPS65994 EVM User Guide SLVUBM1C – JANUARY 2019 – REVISED JANUARY 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
