Texi Forte UF User Manual

Adjustment
34
13.05.02 Positioning the feed dog in the direction of sewing
Requirement
With the longest stitch set, the bottom feed dog must have the same clearance the front
and the back with respect to the needle-plate cutout when feeding both forwards and
backwards.
Set the longest stitch.
Adjust rock shaft 1 in accordance with the requirement and tighten screws 2.
Fig. 13 - 02
2
1
Texi HD Forte UF instruction manual

Texi Forte UF Specifications

General

Brand	Texi
Model	Forte UF
Category	Sewing Machine
Language	English
