Adjustment
44
13
.05.11 Bobbin-case opener
Requirement
The needle thread must not be clamped between the bobbin-case opener 1 and the bob-
bin-case base 3 nor may it be clamped between projection 4 and the retaining trip of the
needle plate (see arrows).
Thread the machine, insert test material and allow the presser foot to rest on the needle
plate.
Sew a few stitches by turning the handwheel and carry out a check in accordance with
the requirement.
Turn bobbin-case opener 1 (screw 2) in accordance with the requirement.
Fig. 13 - 11
2
3
1
4
Texi HD Forte UF instruction manual
