Adjustment
46
13
.05.13 Needle thread tension release
Requirement
With the presser foot raised, both of the tension discs must be at least 0.5 mm apart.
Raise the presser foot using the hand lever.
Align the compression plate 1 behind the tension bearing board 2 in accordance with
the requirement.
If the tension is correct, release pin 3 must not be under pressure.
Fig. 13 - 13
2
3
1
The clearance of 0.5 mm is a minimum and can increase to more than 1 mm
when using thick threads.
Texi HD Forte UF instruction manual
