Texi Joylock 2/464
EN
During the sewing with edge knife you
can use lint tray. Mount fastener A1 to
hole A, and bolt from left side put above
hole B (as it is shown on the picture).
With the lint tray located in this position,
it will collect all your waste material.
After completion of work if you then turn
tray upwards in direction shown, nger
Ref C will locate in slot D and left hand pin will slide into lower hole B.
When using cutting width gauge, the
fabric is cut down and sewn at same
distance from the edge of fabric. Within
the distance of the width adjusted.
Thread cutter is built in needle plate.
Make sure that power switch is o, then
trim thread near the end of fabric by
pushing down lever as illustrated.
LINT TRAY
CUTTING WIDTH GAUGE
THREAD CUTTER
