ZONE 2 — TAIL ROTOR ASSEMBLY
Chapter 11 PLACARDS AND MARKINGS
1. Examine the placards, decals, and markings. Make sure
they are readable, correctly applied, and in agreement with the
applicable configuration of your helicopter.
Chapter 64 TAIL ROTOR ASSEMBLY
1. Clean tail rotor blades to maintain visibility of warning
stripes.
BHT-206A/B/L-Series-
CR&O,
Chapter 64
2. Examine the following tail rotor hub assembly components
for condition and security of attachment:
a. Yoke
b. Pitch horns
c. Trunnion and trunnion caps
d. Counterweight hardware
Chapter 64 3. Examine tail rotor blades as follows:
a. Tip block rivets for damage, corrosion, erosion, and
looseness.
b. Skin for bulges, nicks, dents, scratches, or other
damage.
c. Deformed or cracked skin in the area of the chordwise
weights.
d. Leading edge for erosion, nicks, dents, or scratches.
e. Bonded joints of blade skin mating area for suspected
voids or cracks. Pay particular attention in the area of tip block
and doublers.
f. Feathering bearings for looseness and cracks in uniball.
5-16. 100-HOUR AIRFRAME PROGRESSIVE INSPECTION — EVENT NO. 1 (CONT)
