8. Examine forward deck drains to ensure absence of
obstruction.
9. Examine antennas for condition and security.
Chapter 67 CONTROLS
1. Examine the following flight control components for signs
of interference, corrosion, wear, mechanical damage, and
security:
a. Control tubes
b. Links
c. Rod and bearings
d. Bellcranks
e. Bellcrank supports
f. Attaching bolts and nuts
2. Inspect main rotor pitch links with a 3X magnifying glass for
damage, corrosion, and cracks. Give particular attention to
swaged ends at jam nut or inserts.
Chapter 76 3. Examine N
2
control linkages on forward deck for condition
and security. Pay particular attention to the jackshaft assembly
for damage or evidence of twisting.
4. Verify all control tubes and bellcranks for freedom of travel
throughout range.
Chapter 62 and
Chapter 63
SWASHPLATE ASSEMBLY AND MAST
1. Clean swashplate assembly and mast.
2. Disconnect main rotor pitch links from outer ring.
3. Disconnect idler (drive) link from outer ring.
5-16. 100-HOUR AIRFRAME PROGRESSIVE INSPECTION — EVENT NO. 1 (CONT)
DATA REFERENCE INSPECTION TASK DESCRIPTION
INITIAL
MECH OTHER
To Next Page
