Textron Bunton EC Hydro Midsize 930024 - Page 53

Parts-27
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
EC
Hydro
Midsize
FIGURE 1
UPPER ENGINE DECK ASSY
4115262-01
1-1 2721520 CAP-FUEL GASOLINE 3.5 1
1-2 2722286 TANK-FUEL MID 1
(INCLUDES ITEMS 3 & 4)
1-3 48310 S BUSHING,FUEL TANK 1
1-4 38540 S FUEL SHUT-OFF VALV 1
1-5 88042N HOSE CLAMP 2
1-6 48016-8A HOSE,.25IDX.50ODX17" 16.5"
1-7 38666 FILTER, FUEL 1
1-8 2721105.2 WLDMT-ENGINE DECK 1
1-9 A1105061 BOLT-M12-1.75 X 30 8
1-10 64237-06 LOCKNUT-NYLON M12-1.75 8
1-11 48228-2A CABLE CLIP 3/4 W/INSTN 2
1-12 64163-31 WASHER 3
1-13 64006-03 LOCKWSHR-HELICAL 3/8 4
1-14 48228A CABLE CLIP-INSULATED 2
1-15 64229-02 LOCK NUT-NYLON 5/16-18 4
1-16 2306138 S-EC HYD RSVR W/LABS 1
1-17 64123-15 BLT-HEX 3/8-16X3/4 3
1-18 2722269.2 HANDLE-LOWER HYD 1
1-19 64018-9 BLT-CRG 5/16-18 X 3/4 4
1-20 38542 CLAMP-DOCU TUBE 2
1-21 64006-01 LOCKWSHR-HELICAL 1/4 2
1-22 64123-89 BLT-HEX 1/4-20 X 3/4 2
1-23 38061A COVER 2
1-24 2306144 S DOCU TUBE W/LAB 1
1-25 A1102966 BOLT-M6-1.00X16 1
1-26 * 4114119 ENGINE-15HP KAW ES 1
2722214 FILTER-OIL
2722207 FILTER-AIR
2722208 FILTER-PRE
(SERVICE MANUAL 15 HP KAW #99920-2129-03)
1-27 64123-50 BLT-HEX 3/8-16 X 1 1
1-28 64211-01 WSHR-ALUM,BACKING 2
1-29 64002-04 L'WSHER, EXT. 5/16 1
1-30 64215-02 RIVET-POP IFI# 44 2
1-31 4116244 GUARD-MUFFLER 1
1-32 4116332 MUFFLER-15HP KAW EC 1
1-33 64215-04 RIVET-POP IFI# 42 5
1-34 4116243 COVER-MUFFLER 1
* AVAILABLE THROUGH KAWASAKI DEALER
