Textron Bunton EC Hydro Midsize 930024 - Cutterdeck Mounting

Parts-47
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
EC
Hydro
Midsize
11-1 2721991.7 PLATE-NUT 2
11-2 64246-04 NUT-WHIZ M12-1.75 12
11-3 64246-03 NUT-WHIZ M10-1.50 2
11-4 64163-82 WSHR-FLAT.406X1.44X9GA 2
11-5 A1104057 BLT-METRIC M10-1.50X25 2
11-6 64263-018 BLT-FLG HD M12-1.75 X 30 4
FIGURE 11
CUTTERDECK MOUNTING
2721693-10
