Parts-37
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
EC
Hydro
Midsize
FIGURE 6
TRACTION CONTROLS
2721734-07
6-1 2722426 GRIP-TRACTION LOCK 2
6-2 38189 SPRING-COMPRESSION 2
6-3 64061-37 ROLL PIN-1/8 X 1.00 SS 2
6-4 33288 STUD-DOUBLE ENDED 2
6-5 62464-5A WASHER,THRUST 5/16X3/4 2
6-6 33243 SPACER 2
6-7 2722242 TRACTION LOCK LH 1
* 2722243 TRACTION LOCK RH 1
6-8 64229-02 5/16-18 NYLON LOCKNUT 4
6-9 64229-01 LOCK NUT NYL 1/4-20 2
6-10 2308002 BRG-RADIAL W/THD STUD 2
6-11 64175-01 PUSH NUT 2
6-12 2308080 BEARING SELF ALIGNED 2
6-13 2306083.7 WLDMT SPEED CNTRL RH 1
6-14 64168-2 HAIRPIN COTTER 8
6-15 2308065 SPRING EXTENSION 2
6-16 2721660 WLDMT-PUMP ARM RH 1
* 2721622 WLDMT-PUMP ARM LH 1
6-17 2722305 ROD-SPEED CONTROL 2
6-18 2306084.7 WLDMT SPEED CNTRL LH 1
6-19 64163-06 WSHR.768/.756X1.25X14GA 2
6-20 85010N ZERK, 1/4-28 STR 2
6-21 2721583.2 WLDMT-HYD UPPER HNDL 1
6-22 64061-28 ROLL PIN 3/16 X 1 1/4 2
6-23 2721617.7 WLDMT-SPEED CONTROL 2
6-24 2722269.2 HANDLE-LOWER 1
6-25 64123-50 BOLT, 3/8-16X1 HEX 2
6-26 2306081.7 WLDMT PUMP ARM 2
6-27 * 2308121 ADHESIVE 1
(USE WITH 38009N GRIP)
6-28 64123-67 BLT-HEX 3/8-16X2 1
6-29 64123-68 BLT-HEX 5/16-18 X 1 2
6-30 64139-13 BLT-WLF 5/16-18X1/2 4
6-31 64163-02 WSHR 21/64X19/32X11 GA 10
6-32 38372 BEARING BALL 4
6-33 35011A SPRING CNTRL DETENT 1
6-34 33103 SWIVEL 4
6-35 33286 ROD TRACTION CNTRL 2
6-36 31032 LEVER TRACTION CNTRL 2
6-37 38009N GRIP TRACTION CNTRL 2
6-38 64163-61 WASH 25/64X1X12 GA 2
6-39 64188-34 PIN-CLEVIS .19 WHOLE 2
6-40 64141-6 NUT-WLF 5/16-18 6
6-41 4113987 SPRING EXTENSION 2
6-42 64205-011 BLT-METRIC M10-1.50 X 40 2
6-43 64246-03 NUT-WHIZ M10-1.50 6
6-44 64123-202 BLT-HEX 3/8-16 X 9 1
6-45 64229-03 NUT-NYLOCK 3/8-16 4
6-46 2308066 FRICTION WASHER 4
6-47 68156A HANDLE KNOB BLACK 2
6-48 2308076-02 BEARING-PLASTIC 2
6-49 64192-04 SCREW 5/16-18 2
6-50 2303058 ECCENTRIC SHAFT W/ZRK 2
6-51 64123-02 BLT HEX 3/8-24 X 1 2
6-52 64006-03 LOCKWASHER 3/8 2
6-53 64144-16 SNAP RING 2
6-54 64123-70 BLT-HEX 3/8-16X1-1/2 2
6-55 64141-4 NUT-WLF 3/8-16 4
6-56 64123-69 BOLT-5/16-18X1-1/2 HEX 2
6-57 64163-31 WASHER, 25/64 X 1 X 12 4
TRACTION LOCK ASSY'S ARE ALSO AVAILABLE
4113565 S-TRCTN LOCK ASSY RH 1
(INCLUDES ITEMS 1-4, 6, 7, 9-12)
4113564 S-TRCTN LOCK ASSY LH 1
(INCLUDES ITEMS 1-4, 6, 7, 9-12)
* NOT ILLUSTRATED
