Textron Bunton EC Hydro Midsize 930024 User Manual

GB-4
EC
Hydro
Midsize
ASSEMBLY/SET-UP INSTRUCTIONS
5. Bolt upper handle B to lower handle D with
(2) 3/8-16 X 1" bolts and nuts at location E bolts
removed in the previous step and
(2) 3/8-16 X 1-1/2" bolts and nuts at location F.
4. Unbolt upper handle B from shipping bracket C.
Unbolt shipping bracket C from lower handle D.
Retain fasteners removed for later use.
6. Reinstall spring F to bolt on both sides. Install
3/8-16 nylon locknut to end of bolt on both sides
as shown.

Textron Bunton EC Hydro Midsize 930024 Specifications

General

Brand	Textron
Model	Bunton EC Hydro Midsize 930024
Category	Lawn Mower
Language	English
