Textron Bunton EC Hydro Midsize 930024 User Manual

Parts-29
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
EC
Hydro
Midsize
FIGURE 2
LOWER ENGINE DECK ASSY/CLUTCH
4115262-02
2-1 2721647 PULLEY-4.50E.O.D. 1
2-2 64163-31 WASHER, 25/64 X 1 X 12 5
2-3 2721110 CLUTCH-ELECTRIC 1
2-4 2721331.7 WLDMT-CLUTCH STOP MID 1
2-5 2721642 BELT-HA 49.0 1
2-6 2722244 PULLEY- A SECTION 4.50 2
2-7 38304-03 BRG-FLANGED PLASTIC 1
2-8 2721398 PIN-CLUTCH 1
2-9 64264-01 BLT-WLF M10-1.5 X 16 1
2-10 2721641.7 WLDMT-IDLER ARM 1
2-11 2721652 PIN-PIVOT 1
2-12 64163-65 WASHER 0.890 X 1.375 6
2-13 64163-82 WSHR-FLAT.406X1.44X9GA 2
2-14 64205-012 BLT-METRIC M10-1.50 X 90 1
2-15 64237-03 LOCKNUT-NYLON M10-1.5 3
2-16 2308000 PULLEY-IDLER 4.00 EOD 1
2-17 33148-01 SPACER 1
2-18 38219 SPRING-TENSION 1
2-19 64123-87 BLT-HEX 3/8-16 X 1-3/4 1
2-20 64141-4 NUT-WLF 3/8-16 1
2-21 64246-03 NUT-WHIZ M10-1.50 2
2-22 64197-005 BLT-TDFM 3/8-16X1-1/4 4
2-23 64123-155 BLT-HEX 7/16-20 X 3 1
2-24 64006-06 LOCKWSHR-HELICAL 7/1 1
2-25 64205-001 BLT-METRIC M8-1.25 X 20 2
2-26 64251-003 WHSR-M8 2
2-27 64237-05 LOCKNUT-NYLON M8-1.25 2
2-28 64164-12 1/4X1/4X1 SQ END KEY 1
2-29 64205-17 BLT-METRIC M10-1.50 X 75 2
2-30 2720949 ASSY-CLUTCH WIRE 1
2-31 2721615 PUMP-HYDRO LH 1
2-32 4112782 PUMP-HYDRO RH 1
2-33 2721541 PULLEY-IDLER 5 IN 1
2-34 2721401.7 WLDMT-IDLER ARM 1
2-35 64163-61 WSHR .81X.406X16GA 1
2-36 64205-036 BLT-METRIC M10-1.50 X 35 4
2-37 2188131 SPRING-EXTENSION 1
2-38 2721105.2 WLDMT-ENGINE DECK 1
2-39 2721723 PIN-PIVOT 1
2-40 64205-011 BLT-METRIC M10-1.50 X 40 1
2-41 64044-6 SCREW-SET 5/16-18X1/4 4
2-42 64238-03 KEY-METRIC 5MM SQ X 28 2
2-43 64209-09 WASHER-CONICAL SPRING 2
2-44 148034-08 INSUL. GROMMET 1.125OD 1
2-45 64205-013 BLT-METRIC M6-1 X 12 2
2-46 64265-05 NUT-FL NYLOCK M10-1.5 4
2-47 64163-51 WSHR.453 X 1.38 X 7GA 1
2-48 64163-31 WASHER, 25/64 X 1 X 12 1
