Parts-31
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
EC
Hydro
Midsize
FIGURE 3
DRIVE WHEELS
4115262-03
3-1 2721105.2 WLDMT-ENGINE DECK 1
3-2 2721620.7 WLDMT-HUB 2
3-3 2721956 ASSY-WHEEL 16 X 7.50 X 8 2
2721956-01 TIRE-16X7.50 X 8 MLTI TRC 1
2721956-02 WHEEL W/ DUAL VALVES 1
3-4 64267-01 NUT-HEX FLANGED 1/2-20 8
3-5 64025-06 NUT-HEX 3/4-16 2A 2
3-6 2308051 MOTOR-WHEEL ROSS MF 2
3-7 64246-04 NUT-WHIZ M12-1.75 8
3-8 64164-28 #808 WOODRUFF KEY 2
3-9 64205-028 BLT-METRIC M12-1.75 X 60 8
