Parts-33

ITEM PART NO. DESCRIPTION QTY

Hydro

Midsize

FIGURE 4

PARKING BRAKE

2721734-04

4-1 2721637 WLDMT-BRAKE SHAFT 1

4-2 33103 SWIVEL 1

4-3 64168-2 COTTER-HAIRPIN.08X1.19 2

4-4 64246-03 NUT-WHIZ M10-1.50 2

4-5 64205-012 BLT-METRIC M10-1.50 X 90 1

4-6 2188131 SPRING-EXTENSION 1

4-7 64163-17 25/64 X 2 X 11GA WASHR 1

4-8 64171-2 WAVE WASHER 1

4-9 2188145 BEARING-.75ID SELF ALIGN 2

4-10 64205-001 BLT-METRIC M8-1.25 X 20 4

4-11 64246-02 NUT-WLF M8-1.25 4

4-12 2721725.7 WLDMT-SCRUBBER 2

4-13 64061-09 ROLL PIN-3/8 X 2 4

4-14 64237-03 LOCKNUT-NYLON M10-1.5 1

4-15 2721726 ROD-BRAKE 1

4-16 2721632.7 LEVER-BRAKE 1

4-17 38404-01 GRIP-CONTROL LEVER 1

4-18 A110406 BOLT-M10-1.5 X 30 1

4-19 64163-02 WSHR-.321 X .593 X 11GA 1

Textron Bunton EC Hydro Midsize 930024 - Page 59
