Parts-35

ITEM PART NO. DESCRIPTION QTY

Hydro

Midsize

FIGURE 5

ELECTRIC START UPPER HANDLE

4115262-05

5-1 38360 GRIP-RECESSED 1 IN 2

5-2 * 2308121 ADHESIVE-3 GRAM TUBE 1

(USE WITH 38360 GRIP)

5-3 128010 KEY SWITCH 1

5-4 64152-46 SCR-SLT HH 10-24X1/2 2

5-5 4115089 S-CNTRL PNL W/LAB EC 1

5-6 2303023 CONNECTOR-OP 2

5-7 33030-09 IDLER-BUSHING 2

5-8 2308037 SPRING, TORSION OP 1

5-9 38371-01 BRG-NYLINER 3/8 2

5-10 64025-15 NUT-HEX #10-24 KEPS 2

5-11 2722269.2 HANDLE-LOWER 1

5-12 2308094 SWITCH-NCNC DBL POLE 1

5-13 2721583.2 WLDMT-HYD UPR HANDLE 1

5-14 64123-50 BOLT, 3/8-16X1 HEX 2

5-15 64123-70 BLT-HEX 3/8-16X1-1/2 2

5-16 2188178 SWITCH-RETAINER 1

5-17 64141-4 NUT-WLF 3/8-16 4

5-18 2308152 LEVER-OP LH 1

5-19 2308153 LEVER-OP RH 1

5-20 2306097 WLDMT-ACTUATOR-PLATD 1

5-21 2721505 SWITCH-PTO 1

5-22 38357-04 CONTROL-THROTTLE 1

5-23 48412 CLIP-CABLE 5/8 J X 8.74 1

5-24 64152-23 1/4-20X3/8 LG SP SCREW 4

5-25 64197-015 BLT-TDFM 10-32X1/2 TORX 4

5-26 64197-002 BLT-TDFM 1/4-20X3/4 4

5-27 108208 SWITCH DBL POLE 1

* NOT ILLUSTRATED
