Parts-39
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
EC
Hydro
Midsize
FIGURE 7
ELECTRIC START BATTERY
4115262-07
7-1 64229-02 LOCK NUT-NYLON 5/16-18 2
7-2 64163-29 WASHER 2
7-3 128035 COVER-BATTERY 1
7-4 2721105.2 WLDMT-ENGINE DECK 1
7-5 64123-54 BOLT, 5/16-18X3/4 HEX 2
7-6 112386 BOOT-BATTERY TERM POS 1
7-7 108055 BATTERY 1
7-8 108061-16 CABLE-BTTRY 31.5 BLACK 1
7-9 64025-02 NUT-HEX 5/16-18 2
7-10 4115331 S-TRAY, BATTERY 1
7-11 2722227-03 CABLE-BTTRY W/CONDUIT 1
7-12 2722202.7 SUPPORT-BATT TRAY 2
7-13 64197-016 BLT-TDFM 3/8-16X1/2 8
7-14 123026 ROD,BATTERY HLD DWN 1
7-15 38665 SOLENOID 1
7-16 64152-23 1/4-20X3/8 LG SP SCREW 2
7-17 108061-15 CABLE-BATTERY 6.5 RED 1
7-18 64141-2 NUT-WLF 1/4-20 1
