Parts-41
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
EC
Hydro
Midsize
FIGURE 8
HYDRAULICS
4115262-08
NOTE:
DO NOT use teflon tape on any hydraulic
fittings. Use a liquid pipe sealant.
SERVICEABLE HYDRAULIC O-RINGS
8-1 58026-01 3-WAY CONNECTOR 2
8-2 108029 PLUG, MAGNETIC 1
8-3 158058-04 FITTING-90 BARB, ADJ. 2
8-4 108205-02 ELBW-MALE 45 8X8 37-ORB 4
8-5 88042-04 CLAMP-HOSE 5/8" 12
8-6 2720396 FLTR, 25 MCRN SM CAM 1
8-7 69060-01 FTG-BARB 9/16 X 3/8 ST 2
8-8 69216.7 CAP-RESERVOIR 1
8-9 64123-60 BOLT, 1/4-20 X 2 HEX 2
8-10 64229-01 LOCK NUT-NYLON 1/4-20 2
8-11 2306138 S HYD RESER W/LABS EC 1
8-12 2308051 MOTOR WHEEL ROSS 2
8-13 2692300-01 HOSE-1/2 37/ORB X 18.5 LG 2
8-14 2692300-02 HOSE-1/2 37/ORB X 18.5 LG 2
8-15 4112782 PUMP-HYDRO LH 1
(SEE FIG 10 FOR PARTS BREAKDOWN)
8-16 2721615 PUMP-HYDRO RH 1
(SEE FIG 10 FOR PARTS BREAKDOWN)
(69053-05 IS A SERVICEABLE LENGTH OF 55")
8-17 69053-05 3/8 HI TEMP HOSE 17.0" 1
8-18 69053-05 3/8 HI TEMP HOSE 5.0" 1
8-19 69053-05 3/8 HI TEMP HOSE 5.0" 1
8-20 69053-05 3/8 HI TEMP HOSE 7.5" 1
8-21 69053-05 3/8 HI TEMP HOSE 6.8" 1
8-22 69053-05 3/8 HI TEMP HOSE 12.0" 1
GNIR'O'TROPEAS
TRAP
REBMUN
EZISDAERHT #865-SA
01-160851 81-61/9 609-
11-160851 61-4/3 809-
21-160851 41-8/7 019-
31-160851 21-61/1-1 219-
41-160851 21-61/5-1 619-
61-160851 21-8/5-1 029-
30-160851 21-8/7-1 429-
