Textron Bunton EC Hydro Midsize 930024 User Manual

Parts-45
EC
Hydro
Midsize
FIGURE 10
HYDROGEAR PUMP
2721734-14
4112782 PUMP-HYDRO LH ILLUSTRATED AS SHOWN
2721615 PUMP-HYDRO RH ILLUSTRATED AS SHOWN EXCEPT GROUP A IS ROTATED 180°
AROUND
THE CENTERLINE OF THE PUMP.
10-1 70516 ----- HOUSING KIT 1
10-2 70517 ----- END CAP KIT 1
10-3 50641 ----- STRAIGHT HEADLESS PIN 2
10-4 50969 2721615-01 FLANGE BOLT M8-1.25 X 60 4
10-5 51232 2721615-02 HOUSING O-RING 1
10-6 2513027 2721615-03 CHARGE PUMP KIT (STD) 1
10-7 50273 2721615-04 STD GEROTOR ASSEMBLY 1
10-8 9004101-1340 2721615-05 O-RING 1
10-10 50095 2721615-06 SOCKET HEAD M6-1.0 X 20 2
10-15 2513030 ----- BYPASS VALVE KIT (BLANK) 1
10-18 70521 2721615-07 PUMP SHAFT KIT 1
10-19 50315 ----- BALL BEARING 17 X 40 X 12 1
10-20 51161 ----- LIP SEAL 17 x 40 x 12 1
10-21 50951 ----- SPACER 1
10-22 50329 ----- RETAINING RING 1
10-25 70331 2721615-08 CYLINDER BLOCK KIT 1
10-29 2003014 ----- BLOCK SPRING 1
10-30 2003017 ----- BLOCK THRUST WASHER 1
10-31 51246 2721615-09 VALVE PLATE 1
10-32 2003087 2721615-10 SWASHPLATE 1
10-34 50551 2721615-11 BALL THRUST BEARING 1
10-37 2003005 2721615-12 TRUNNION ARM 1
10-38 2000015 2721615-13 SLOT GUIDE 1
10-42A 2510027 2721615-14 CHECK VALVE KIT (.031") 1
10-42B 2510050 2721615-15 CHECK VALVE KIT (BLANK) 1
10-44 70403 2721615-16 CHARGE RELIEF VALVE KIT 1
10-49 2513043 2721615-17 TRUNNION SEAL/RETAINER KIT1
10-56 9005110-4400 ----- STRAIGHT THREAD PLUG 1
10-66 9005110-3100 ----- 5/16 SAE PLUG 1
10-100 70525 2721615-18 OVERHAUL SEAL KIT 1
ITEM HYDROGEAR PART NO. TEXTRON PART NO. DESCRIPTION QTY

Textron Bunton EC Hydro Midsize 930024 Specifications

General

Brand	Textron
Model	Bunton EC Hydro Midsize 930024
Category	Lawn Mower
Language	English
