Textron Bunton EC Hydro Midsize 930024 - Page 75

Parts-49
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
EC
Hydro
Midsize
12-1 2721110 CLUTCH-ELECTRIC 1
(INCLUDES ITEM 2)
12-2 2720949 ASSY-CLUTCH WIRE 1
12-3 108208 SWITCH DBL POLE 1
12-4 128010 KEY SWITCH 1
12-5 2308094 SWITCH-NCNC DBL POLE 1
12-6 148082-20 FUSE 20 AMP 2
12-7 2721505 SWITCH-PTO 1
12-8 2721727 HARNESS-HYDRO MAIN 1
(INCLUDES QTY OF 2 OF ITEM 6)
12-9 38665 SOLENOID-STARTER 1
12-10*108061-15 CABLE-BATTERY 6.5 RED 1
(FROM STARTER SOLENOID TO STARTER)
12-11*2722227-03 CABLE-BTTRY W/CONDUIT 1
(FROM (+) POSITIVE BATTERY TERMINAL
TO STARTER SOLENOID)
12-12*108061-16 CABLE-BTTRY 31.5 BLACK 1
(FROM (-) NEGATIVE BATTERY TERMINAL
TO ENGINE BLOCK)
* NOT ILLUSTRATED
FIGURE 12
ELECTRICAL DIAGRAM
2721734-12
