5 DECALS
23
WARNING
To prevent injury when you fold the ROPS, use caution to prevent your fingers
broken between moving and rigid parts of the ROPS.
5.2 INSTRUCTION DECALS ____________________________________________________
Height of cut adjustment
NOTICE
Do NOT fold this ROPS
if a canopy is attached.
Damage to the mower
hood could result.
!
WARNING
This structure's
proctective capability
may be impaired by
structural damage,
overturn, or alteration.
If any of these
conditions occur, this
structure must be
replaced.
5003597
3/4
1
1-1/4
1-1/2
1-3/4
2
2-1/4
2-1/2
2-3/4
3
3-1/4
3-1/2
3-3/4
4
4-1/4
4-1/2
4-3/4
5
5-1/4
CUT
HEIGHT
W/ 1/2
SPACERS
CUT
HEIGHT
W/ 1/4
SPACER
4133609
