TFT HURRICANE Series - Monitor Models and Terminology

©Copyright Task Force Tips LLC 2004-2020 6 LIX-300 October 23, 2020 Rev22
3.5 VARIOUS MODELS AND TERMS
Figure 3.5A
Figure 3.5B
HURRICANE MONITOR
(XFI-FPNJ)
Rotation
Handle
Elevation
Handwheel
Serial #
Rotation
Lock Lever
Flange
Pressure Gauge
Port
Grease
Zerk
Grease
Zerk
Automatic
Drain
Built In Stream
Straightener
HURRICANE TILLER
(XFIH-T series)
Elevation
Handwheel
Serial #
Rotation Handle
(Tiller Bar)
Pressure Gauge
Port
Rotation
Lock Knob
Grease
Zerk
Grease Zerk
Automatic
Drain
Built In Stream
Straightener
