13. BODY COVER
Remove seat.
Remove 3 bolts from battery fixed.
Remove battery fixeds.
Remove 2 wire from battery.
Remove battery.
Remove 2 bolts from battery fixed.Then,remove
cable.
Remove 1 couplers from starting motor relay , and
then remove starting motor relay.
Remove bolts (each side 1 bolts) and 2 couplers
Remove fuse box.
Installation
Install in reverse order of removal procedures.
13-3
