TGB 525 - Rear Brake & Rear Wheel & Rear Cushion

16. REAR BRAKE & REAR WHEEL & REAR CUSHION
Mechanism Diagram···························16-1
Maintenance Description ···················16-2
Trouble Diagnosis ······························16-3
Rear Wheel ··········································16-4
Disk Brake System Inspection ··········16-5
Rear Wheel Axle ·································16-6
Adding Brake Fluid ···························· 16-8
Brake fluid replacement / Air-bleed ·· 16-9
Rear Brake Caliper ····························· 16-10
Brake Disk ·········································· 16-11
Rear Brake Master Cylinder ·············· 16-11
Rear Cushion······································ 16-14
Mechanism Diagram
Switch assy
Brake hose assy
Limited switch
Distributor Protective cover
Choke cable
Rear caliper Pedal master cylinder
Brake pedal
Rear axle housing Rear axle
Tire
Rear shock absorber
Rear fork
Rear wheel hub
Rim
16-1
