17. ELECTRICAL SYSTEM
Maintenance Data
Operational precaution
●
When remove the battery, the disconnection sequence of cable terminals shall
be strictly observed.
(First disconnect the negative cable terminal, next, the positive cable terminal.)
●
The model of the spark plug and the tightening torque.
●
The
ignition
timing.
●
Adjustment of headlight.
●
Removal and installation of
AC generator.
●
The maintenance free battery requires no inspection of electrolyte level and refilling of
distilled water.
●
To recharge
the battery, remove the battery from rack without
removing ventilation
caps.
●
Unless in emergency, never rapid charge the battery.
●
The voltage must be checked with the voltmeter
while charging the battery.
●
As C.D.I assembly does not require
an ignition timing check. In case ignition timing is incorrect,
check
C.D.I and
AC generator. Verify with an ignition timing light after replacement if necessary.
Technical Specification
Charging system
Description
Specification
Battery
Capacity
12V18Ah
Charging rate
1.4A / 5 ~ 10 hours (standard)
14A / 0.5 hour (fast charging)
Leak current
< 1mA
Charging current
1.2
A / 1500rpm
Control voltage in charging
14.5 + 0.5 V / 1500rpm
Ignition system
Description
Specification
Spark plug
Ignition coil
and
Model
NGK CR7E (Recommended)
Gap
0.8mm
Primary winding
2.9
± 10%Ω
Without cap: 15.
± 10KΩ
resistance
Secondary winding
Ignition
timing “F”
mark
With cap:20
± 10KΩ
15°
TDC / 1500rpm
31°TDC / 4200rpm
17-2
