5 General Characteristics
The following table lists absolute maximum ratings for the LGA DevKit. Please note that viola-
tion of these limits may cause permanent damage to the LGA DevKit.
The following table lists recommended operating and environmental conditions for the LGA
DevKit.
Table 2: Absolute maximum ratings
Parameter Min Max Unit
Voltage on USB ports -0.3 5.5 V
Voltage on DSB port -0.3 5.5 V
Voltage on signal pin header, depending on used module -0.3 2.1 V
Current signal pin header, depending on used module -10 +10 mA
Voltage on external reference -0.3 6 V
Socket single contact continues current 2 A
Table 3: Operating and environmental conditions
Parameter Min Max Unit
Recommended operating condition 0 45 °C
Storage temperature 0 85 °C
Supply voltage on USB port 4.75 5.25 V
Supply current capability on USB port 1 A
Socket single contact resistance (Rev1) 80 120 mOhm
Socket single contact resistance (Rev1.1) 25 35 mOhm
Socket spring life cycle 100,000
