1.3 Package Content
The following packages are available for the LGA DevKits. Normally an LGA DevKit SM or L
would be used with the LGA DevKit socket SML:
•Cinterion
®
LGA DevKit SM (Ordering number: L30960-N0111-A100)
- Base PCB for the industrial platform modules
- USB and SMA cable
- An ultra-wideband high efficiency antenna
- A bag of jumpers ~25pcs
- A quick start guide
•Cinterion
®
LGA DevKit L (Ordering number: L30960-N0112-A100)
- Base PCB for the industrial plus platform modules
- USB and SMA cable
- An ultra-wideband high efficiency antenna
- A bag of jumpers ~25pcs
- A quick start guide
•Cinterion
®
LGA DevKit socket SML (Ordering number: L30960-N0110-A100)
- The needle socket fitting on both PCB versions SM and L
- Screws, fixing frames, retention lid
Figure 1 shows the LGA DevKit package contents, whereas Figure 2 shows how the LGA
DevKit socket SML can be used for both LGA DevKit variants S and M.
Figure 1: LGA DevKit SM package content
USB cable
LGA DevKit
Antenna
SMA cable
Jumpers
Quick Start
Guide
(SM or L)
