— E6 —
Connection
Connecting to AC Power
Connecting to Line In Jack
Insert the small end of the AC adapter
into the DC IN jack on the rear of the unit.
Insert the other end (with the 2 blades)
into a conveniently located AC outlet
having 120V AC, 60Hz.
Note: Make all connections before
connecting to AC power.
Connect an external device by using an
appropriate cable (3.5mm audio cable not
included) as shown.
Note: See page E18 to select and use the
Line In function.
To External Unit
AUDIO OUTPUT
/ HEADPHONE JACK
Disco Lights
1
To illuminate the disco light and get
your desired lighting effect, slide the
Disco Light DIMMER slide switch
from the MIN position to your desired
level.
u
To Next Page
