N4100PRO
The N4100PRO’s hard disk
trays each have a lock, a latch,
and two indicators.
N4200 series/N5200XXX/N5500:
Each of the N4200 series/N5200XXX/N5500’s hard disk trays has a lock, a latch,
and two LED indicators:
Hard Disk Trays
Item Description
1.HDD Power LED Solid blue: Hard disk is powered on(No function on N4200 series)
2.HDD
Access/Error LED
Blinking green: System is accessing data on the hard disk
Solid red: HDD fail (No function on N4200 series)
3.Lock Use the lock to physically secure the hard disk to the unit.
4.Handle Pull to remove the HDD tray.
Item Description
Lock The tray lock lets you physically secure the HDD with
accessory keys.
Latch Use the latch to open and remove or close and secure the tray.
HDD Power LED Solid blue: HDD is powered on
Access/Error LED Blinking yellow: data is being accessed
Blinking red: hard disk error
