Chapter 4: System Administration
Overview
The Thecus IP storage provides an easily accessible Web Administration
Interface. With it, you can configure and monitor the Thecus IP storage anywhere
on the network.
Web Administration Interface
Make sure your network is connected to the Internet. To access Thecus IP storage
Web Administration Interface:
1. Type the Thecus IP storage IP address into your browser. (Default IP address
is http://192.168.1.100)
NOTE
Your computer’s network IP address must be on the same subnet as the Thecus
IP storage. If the Thecus IP storage has default IP address of 192.168.1.100,
your managing PC IP address must be 192.168.1.x, where x is a number
between 1 and 254, but not 100.
NOTE
This page can be displayed with Flash or with HTML. Choose Flash for Flash
(shown in the top figure) and Traditional for HTML (shown in the bottom
figure).
