WAN/LAN1 Configuration
Item Description
Host name Host name that identifies the Thecus IP storage on the network.
Domain name Specifies the domain name of Thecus IP storage.
WINS Server To set a server name for NetBIOS computer.
MAC Address MAC address of the network interface.
Jumbo Frame Support Enable or disable Jumbo Frame Support of the WAN/LAN1 interface on your
Thecus IP storage.
IP Sharing Mode When enabled, PCs connected to the LAN2 port will be able to access the
WAN/LAN1.
Link Aggregation Specifies whether WAN/LAN1 and LAN2 ports will be aggregated and act as
one port. There are 6 modes can be choose from:
Load Balance/Fail-over/Balance-XOR/802.3ad/Balance-TLB/Balance-ALB
Set IP Address by:
Static / Dynamic
You can choose a static IP or Dynamic IP, and input your network
configuration
IP IP address of the WAN/LAN1 interface.
Netmask Network mask, which is generally: 255.255.255.0
Gateway Default Gateway IP address.
DNS Server Domain Name Service (DNS) server IP address.
NOTE
• Only use Jumbo Frame settings when operating in a Gigabit environment
where all other clients have Jumbo Frame Setting enabled.
• Enabling DHCP automatically turns on UPnP— see the Service Support Screen.
• If you are only using the WAN/LAN1 port, we suggest that you disable IP
Sharing Mode. This will result in higher throughput.
• A correct DNS setting is vital to networks services, such as SMTP and NTP.
• To use the Link Aggregation with “802.3ad selected” feature, please make sure
the networking equipment on the other end of Ethernet cable also supports
802.3ad protocol.
