EX-TRAFIRE
®
55SD
Operator Manual, Revision T-33-28
Activating an external DC coil with an external power supply
Activating an external AC coil with an external power supply
Use a diode 1N4007 if
the voltage is 24 VDC
24 VDC
24 VAC
230 VAC
