EX-TRAFIRE
®
55SD
Operator Manual, Revision T-34-38
Operating the machine torch
WARNING
Plasma arc is generated immediately
when the torch trigger is depressed
Plasma arc is generated immediately when the torch trigger is depressed�
The plasma arc will cut quickly through gloves and skin� Make sure the power supply is switched off
before changing consumables�
• Keep away from the torch tip�
• Do not hold the piece that is to be cut and keep your hands away from the cutting path�
• Never point the torch toward yourself or toward others�
• Never use with the pendant control switch�
Alignment of the machine torch
Mount the machine torch perpendicular to the material to be cut, use a square to align the torch
at 0° and 90°, if torch alignment is not possible, check the cutting table for level to obtain a true
vertical cut�
