INTRODUCTION 2-2 Manual 0-2859
6. Overall Dimensions (including handles)
• Length: 27.5 inches (696 mm)
• Width: 12.4 inches (315 mm)
• Height: 17.3 inches (439 mm)
7. Gas Regulator/Filter Assembly Specifications
• Operating Pressure (Output): 70 psi (4.8 bar)
• Maximum input gas pressure: 125 psi (8.6 bar)
• Filter: Coalescent type filter
2.04 Power Supply Options and
Accessories
Refer to Section 6, Parts Lists, for catalog numbers and
ordering information.
A. Single Stage Air Filter Kit
For use with compressed air shop systems. Filters
moisture and particulate matter from the air stream
to at least 0.85 microns.
B. Two Stage Air Filter Kit
For use on compressed air shop systems. Filters mois-
ture and particulate matter from the air stream to at
least 5.0 microns.
C. High Pressure Regulators
High pressure regulators are available. The regula-
tors are used to set the proper pressure for the type gas
being used.
NOTE
Regulators should not be installed with In-Line Air
Filters.
D. Extended Work Cable with Clamp
As an alternative to the standard 20 ft (6.1 m) work
cable & clamp on the power supply, a 50 ft (15.2 m)
work cable with clamp is available.
E. Multi-Purpose Cart
Rugged steel cart on easy-rolling rear wheels and
front-mounted swivel casters. Provides maximum
mobility for the power supply and can also serve as
a display cart. Top shelf is 12 " (305 mm) x 20 (508
mm). Steel handle is 30" (762 mm) high.
