ULTRA-CUT 400 XT
Manual 0-5275 REPLACEMENT PARTS 6-9
6.09 Power Supply Replacement Parts - Left Side
Item # Qty Description Ref. Des. Catalog #
1 1 AC Suppresion PCB 9-9254
2 1 Main Contactor (2 total) W1, W2 9-7318
3 1 Inverter Module, Full 480 VAC (3 total) 9-7330
1
2
3
Art # A11990
