2 Transport, unpacking and setting-up
2.1 Transporting the heat pump
Caution During transportation or lifting of the entire heat pump, the front panel must always be installed as it locks
the other panels construction.
Caution The heat pump must always be transported and stored in a dry area. Secure the heat pump so that it cannot
tip over during transportation.
Caution The heat pump must always be transported and stored standing and in a dry environment. If the heat pump is
laid on the incorrect side it may become seriously damaged as the oil in the compressor can run out in the
pressure pipe and therefore prevent normal function.
When transporting indoors to the installation location it may be necessary to place the heat pump on its back. The time that the heat
pump is transported on its back should be as short as possible. After the heat pump has been lifted up again it must stand upright for at
least an hour before commissioning.
2.2
Unpacking
2.2.1 Unpack the heat pump
1. Check that there is no transport damage.
2. Remove the packaging.
2.2.2
Delivery check
Check that the delivery contains the following components:
Quantity
Name
1 Heat pump
1 Control unit
1 Document set
1 Package (1 x shut-off valve with filter, 1 x outdoor sensor)
2.3 Positioning the Atec heat pump
The location of the outdoor unit is chosen so that neither the own living environment or adjoining properties are exposed to noise inter-
ference.
The device is, to advantage, placed in an environment with lush trees and shrubs with grass surface. Large hard asphalt surfaces and
stone or brick walls around the heat pump should be avoided since they effectively reflect the sound.
Installation Guide
Atec
Thermia Värmepumpar VMBQY102
7
