If the Curve indicator
40
is lit, press or to adjust the entire curve.
▪
Press and drag individual curve points:
▪
If the Curve indicator
40
is not lit individual points can be moved separately by pressing
and to the desired temperature.
Confirm the settings with
The Curve indicator has two modes that can be toggled by pressing the Curve indicator symbol.
40
When lit, the curve is adjusted as one unit.
40
When not lit, individual curve points can be moved separately.
5.7 System information
Check applicable operating data described in the tables below. The information can be found in the sub-menu
System information
Select System information on the Menu screen:
1. Press on the Start screen to open the Menu screen.
2.
Press System information
Operating data
Sensor
Explanation
Outdoor Shows the temperature on the outdoor sensor.
System supply line Shows the temperature on the system supply line.
Desired system supply line Shows the current system requirement value.
Hot water Shows the temperature of the hot water sensor, if hot water production is
permitted.
Supply line (HP) Shows temperature of outgoing radiator temperature from heat pump.
Return line (HP) Shows temperature of incoming radiator temperature to heat pump.
Brine in Shows the current temperature of brine in to the heat pump.
Brine out Shows the current temperature of brine out from the heat pump.
Operating time
Explanation
Compressor run time Shows the number of hours that the compressor has been in operation.
Tap water run time Shows the number of hours that has been used for hot water production.
External heater run time Shows the number of hours that the external heater has been activated.
Version information
In the menu Operating data, version information about the control system software is shown.
User Guide
Mega
VUJSC302 Thermia Värmepumpar
18
