4 Control system
The heat pump has an integrated control system which automatically calculates the heat demand in the build-
ing to ensure that the correct amount of heat is produced and emitted when necessary.
A touch screen is connected to the control system.
The display is used for:
▪
making settings such as:
▪
setting heating
▪
adjusting the heat curve
▪
displaying operating data such as:
▪
temperatures
▪
operating time
▪
version information
4.1 Display description
Start screen
The screen which appears when the system is up and running.
Here you can also carry out comfort adjustment:
1. Drag clockwise or anticlockwise to raise or lower the offset.
Each point represents an increase/decrease of 1°C.
2.
Alternatively, press
or
Menu screen
This screen appears when you have pressed on the start screen.
User Guide
Mega
Thermia Värmepumpar VUJSC302
9
