Symbol description
Fig. 1: The figure shows the standard curve 40
Symbol description
45
(+2)
Shows when the curve is comfort-adjusted. The digit shows how much.
Shows that the comfort adjustment window is inactive. Press on the symbol
to open comfort adjustment.
Shows that the comfort adjustment window is active.
Shows that the heat curve window is inactive. Press on the symbol to open
heat curve settings.
Shows that the heat curve window is active. This window is the default win-
dow.
Shows that the heating settings window is inactive. Press on the symbol to
open heating settings.
Shows that the heating settings window is active.
Press to reset to factory settings.
40
When the curve indicator is lit, press or to move whole curve upwards
or downwards.
40
When the curve indicator is not lit, press or to move individual curve
points upwards or downwards.
