5
Removing and Reinstalling the Ion Source Housing
Removing the Ion Max or Ion Max-S Ion Source Housing
70 TSQ Series Hardware Manual Thermo Scientific
Figure 37. Ion Max source housing (front)
Figure 38. Ion Max-S source housing (front)
Ion source housing
locking lever (2x)
Ion source housing drain
Ion source housing
locking levers
Ion source housing
drain
