APPENDIX 1
Additional SPD121P System Set-ups
SEMI-INTEGRATED SYSTEM
SpeedVac
®
Concentrator
SPD121P
UVS400
Universal Vacuum Source
ANT100
Exhaust recovery
post trap
Vacuum
Tubing
To Pump
COMPONENT HIGH VACUUM SYSTEM
Vacuum
Tubing
DVG50
SpeedVac
®
Concentrator
SPD121P
RVT400
Cold Trap
VLP120
Vacuum Pump
Vacuum Tubing
to Cold Trap
Vacuum Tubing
to Cold Trap
To Cold
Trap
From
Chamber
From Cold Trap
To SpeedVac
®
Concentrator
Flexible
TEFLON
®
Vacuum
Tubing
VPOF110
Vacuum Pump
Oil Filter
11
