Thermoplan TIGER User Manual

20
Service Kit Tiger 60k
Technical Manual
© 2006 by Thermoplan, Subject to change
Tiger REV-7
SECTION 5
70.07.10
70.07.11
70.03.09
Service Kit Tiger CT 60k
Sercive Kit Tiger CTM 60k
Service Kit Tiger CTS 60K
Inspect Clean Replace
Article number Description
72.12.12 Enclosure, assembly
71.16.53 Ventilation work sheet left C
71.16.54 Ventilation work sheet right C
107.530 Drip tray, assembly
108.107 Valve for drainage tray, assembly I
108.106 Shaft sealing ring ø12x19x5 R
Distributor
101.222 Steam outlet NTC, assembly (CTS)
108.530 Kneecap of exit T&V, assembly R
101.383 Seal 1/8“
108.531 Steam pipe NTC with O-ring, assembly R
104.797 O-ring 6.75x1.78
100.453 Milk suction (front), assembly (CTM) I
100.452 Milk suction
Milk outlet I
100.473 Silicone hose ø8.5/4x 500mm I
106.591 Silicone tube ø8.5/4x500mm I
100.447 Suction
72.21.20 POD Tiger, assembly I
115.039 Filter POD R
71.28.40 O-Ring 4.42x2.62 I
72.22.04 Filter POD, assembly R
72.22.08 Milk outlet Tiger, assembly (CTM)
72.40.46 Bean hopper 2 Mills Tiger, assembly C
Distributor Bean hopper I
71.43.66 Closure plate right I
71.43.69 Closure plate left
