Service Kit Tiger 60k
Technical Manual
© 2006 by Thermoplan, Subject to change
Tiger REV-7
SECTION 5
70.07.10
70.07.11
70.03.09
Service Kit Tiger CT 60k
Sercive Kit Tiger CTM 60k
Service Kit Tiger CTS 60K
Inspect Clean Replace
Article number Description
72.01.15 Mechanical module 2 Mills Tiger, assembly
71.01.92 Powder diffuser left grinder R
71.01.93 Powder diffuser right grinder R
71.01.94 Base support R
71.01.97 Cap for powder channel R
71.20.0177 Pipe ø4/2x 430mm E
71.43.04 Toothbelt 10 T5/365-PAZ K
71.43.08 Toothbelt 360-5M-9 K
71.43.09 Toothbelt 610-5M-9 K
72.21.52 Connection MECA-POD E
100.990 Brew chamber, assembly
100.998 Brew chamber with piston, assembly R
104.491 Mobil piston, assembly
103.826 Moving piston head K
104.818 O-ring 10.69x3.53 E
104.360 Filter with clip E
101.005 Brew chamber with guide, assembly
104.651 Brew chamber nut 14x4 R
106.073 Scraper ring G12x19x3/5 K
110.283 Support brew chamber, assembly R
104.947 Guide sleeve P11 1212 E
Support brew chamber R
103.936 Rear support with drive spindel, assembly
105.589 Drive spindle Rondo 14x4 R
101.963 Spring steel plate E
103.957 Front support, assembly R
101.972 Fix piston, assembly R
104.795 O-ring 6.07x1.78 E
104.230 Cuff for piston E
105.559 Pipe ø6/4x 58 E
104.360 Filter with clip E
107.654 Clip collar, assembly R
