22
Service Kit Tiger 60k
Technical Manual
© 2006 by Thermoplan, Subject to change
Tiger REV-7
SECTION 5
70.07.10
70.07.11
70.03.09
Service Kit Tiger CT 60k
Sercive Kit Tiger CTM 60k
Service Kit Tiger CTS 60K
Inspect Clean Replace
Article number Description
72.00.84/72.00.85 Mill right/left Tiger, assembly C
72.00.84 Mill right, assembly
71.01.96 Mill body ø54 C
71.43.10 Mill wheel pair steel right I
71.46.04 Disc for mill ø54 R
72.01.67 Mill upper support, assembly
Mill upper support ø54 C
71.26.74 O-ring 59x2 I
72.01.68 Mill lower support right, assembly
Mill low support ø54 C
71.43.10 Mill wheel pair steel right I
72.01.13 Toothbelt pulley mill ø54, assembly I
72.00.85 Mill left Tiger, assembly
71.01.96 Mill body ø54 C
71.43.11 Mill wheel pair steel rleft I
71.46.04 Disc for mill ø54 R
72.01.67 Mill upper support, assembly
Mill upper support ø54 C
71.26.74 O-ring 59x2 I
72.01.69 Mill lower support left, assembly
Mill low support ø54 C
71.43.11 Mill wheel pair steel rleft I
72.01.13 Toothbelt pulley mill ø54, assembly I
72.22.46 Hydraulic unit CTM int. / WT, assembly (CTM)
71.20.0183 Silicone tube ø8.5/4x 95mm (CTM) E
103.289 Coffee boiler Tiger, assembly
104.882 O-ring 66.68x3.53 R
102.448 Straight connection 4-1/8“, SW13 I
104.167 Solenoid valve 2 ways, assembly
100.426 Plunger with seal R
104.170 Solenoid valve 3-and 2-way, assembly
100.429 Plunger with seal for 3/2 way R
