Thermoplan TIGER User Manual

25
Service Kit Tiger 60k
Technical Manual
© 2006 by Thermoplan, Subject to change
Tiger REV-7
SECTION 5
70.07.10
70.07.11
70.03.09
Service Kit Tiger CT 60k
Sercive Kit Tiger CTM 60k
Service Kit Tiger CTS 60K
Inspect Clean Replace
Article number Description
72.45.26 Milk base modul 2L, assembly (CTM)
Cooling system peltier milk, assembly (CTM) C
72.41.04 Milktank 2L, assembly (CTM) C
71.46.61 Milktank 2L (CTM) C
72.41.11 Suction part milktank, assembly (CTM) C
71.20.04 O-ring 6.07x1.78 R
72.42.96 Cover milktank 2L, assembly (CTM) C
71.44.26 Plug water and milktank C
72.42.38 Milk base modul 4L, assembly (CTM)
Cooling system peltier milk, assembly (CTM) C
72.42.37 Body milk unit 4.0L, assembly (CTM)
71.46.54 Silicone tube ø8.5/4x117mm (CTM) E
72.42.36 Milktank 4L, assembly (CTM) C
72.41.11 Suction part milktank, assembly (CTM) C
71.20.04 O-ring 6.07x1.78 R
72.42.35 Milktank 4L weld (CTM) C
72.42.99 Cover milktank 4L, assembly(CTM) C
71.44.26 Plug water and milktank (CTM) C
72.40.93 Fan unit cooling element (CTM)
71.34.94 Fan 80x80x25 24VDC (CTM) I
