Thermoplan TIGER User Manual

24
Service Kit Tiger 60k
Technical Manual
© 2006 by Thermoplan, Subject to change
Tiger REV-7
SECTION 5
70.07.10
70.07.11
70.03.09
Service Kit Tiger CT 60k
Sercive Kit Tiger CTM 60k
Service Kit Tiger CTS 60K
Inspect Clean Replace
Article number Description
72.22.17 Mulifunctional bloc, assembly
72.22.18 Expansion valve x, assembly R
Piston Security valve, assembly R
71.22.25 O-ring 17.17x1.78 R
71.53.54 Oval head PT screw Phillips KA40x8 R
72.21.60 Check valve hydr. Block, assembly I
71.20.04 O-ring 6.07x1.78 R
71.20.39 O-ring 9x2 R
71.42.34 Spring check valve hexagonal R
72.21.54 Waterpump with motor, assembly I
72.21.73 Milkpump with motor, assembly (CTM)
71.20.0147 Throttle jet screw (CTM) C
71.20.0165 O-ring ø13x1.3 (CTM) R
71.20.0304 Lip valve (CTM) R
72.23.30 Solenoid valve 3way, assembly (CTM)
72.23.04 Plunger with seal for 3/2 way, teon (CTM) R
71.20.0165 O-ring ø13x1.3 (CTM) R
72.21.98 Milk block Tiger, assembly
71.23.79 O-ring 3.69x1.78 R
72.22.27 Check valve milk block, assembly R
72.21.41 Mini-Elektric valve 2/2 (CTM)
71.23.03 Threaded elbow joint 6-1/8“ SW R
71.20.0165 O-ring ø13x1.3 (CTM) R
72.22.21 Labyrinth disc Thermoblock, assembly (CTM)
71.20.0137 Seal Thermoblock (CTM) R
71.29.28 Labyrinthplate Thermoblock (CTM) C
72.40.75 Airlter basement, assembly
71.43.92 Airlter basement R
72.30.31 Ventilation pillar, assembly
71.42.39 Axial-fan 24VDC, 2W (80x80x25) C
