Service Kit Tiger 60k

Technical Manual

Tiger REV-7

SECTION 5

70.07.10

70.07.11

70.03.09

Service Kit Tiger CT 60k

Sercive Kit Tiger CTM 60k

Service Kit Tiger CTS 60K

Inspect

Clean

Replace

Article number Description

72.70.86 / 72.71.01 Tea Steam Module Tiger 230V / Tea Steam Module Tiger 115V (CTS)

71.20.0420 Straight Schott connection 6-4 (CTS) R

71.20.0421 Straight Schott connection 6-6 (CTS) R

71.20.0479 Silicon hose ø7/10x185mm (CTS) R

71.20.0480 Silicon hose ø7/10x70mm (CTS) R

71.20.0481 Silicon hose ø7/10x45mm (CTS) R

72.23.80 Connection block assembly, TS module (CTS)

10.09.10 O-ring 5x1.5 R

71.20.04 O-ring 6.07x1.78 R

71.20.38 O-ring 6.75x1.78 R

71.20.63 O-ring 2.9x1.78 (CTS) R

71.21.26 O-ring 11.11x1.78 (CTS) R

71.21.27 Seal for 2- and 3-way valve (CTS) R

71.22.10 Filter for 2-way valveblock TS (CTS) R

72.20.39 Plunger with seal for 2- and 3-way valve (CTS) R

72.20.84 Valve check air valve block G1/8“ (CTS) R

100.960 / 108.702 Boiler TS Module Tiger 230V / Boiler TS Module Tiger 115V (CTS)

101.241 Steam valve Ø 4 (CTS)

100.421 Plugger for steam valve(CTS) R

106.478 Security valve TS, assembly (CTS)

100.418 Safety plunger & o-ring SM (CTS) R

104.719 Level probe assembly, TS module Tiger, assembly (CTS)

104.715 Teon pipe probe TS V3 (CTS) R

107.698 Valve 2/2 Lucifer, assembly (CTS)

100.421 Plunger valve ø4mm R
